CW-M frame and shell is 100% Stainless Steel.
More durable and long lasting.
CW-M frame and shell is 100% Stainless Steel.
More durable and long lasting.
Control includes the hard to find larger capacity MBD-3 masonry box.
(Others tell you to supply your own standard 3-gang box or Masonry box. Standard box is a difficult and sub-standard fit. And, the MBD-3 is actually difficult to find and costly ($20-$30.00)
Size: |
Heaters |
Type: |
Sauna Craft |
Bench: |
SAUNA CRAFT CWM SERIES (with external control) |
|
CW-M Sauna Craft heaters : No selection $0.00 |
|
Controls (CW): No selection $0.00 |
Product Price: $0,00
Options amount:
Select a Tab Below for More Info
Sizing & Specifications
Sauna Craft Features
XR Model Warranty
Sauna Craft Manuals
Freight - Heaters
| * Heater Sizing Chart | |||||||
| SIZE (Watts) | VOLTS | PHASE | AMPS | FUSING |
WIRE |
MIN |
MAX |
| 4000 | 240 | 1 | 16.7 | 30 | 10 | 100 | 150 |
| 5000 | 240 | 1 | 20.8 | 30 | 10 | 150 | 250 |
| 6000 | 240 | 1 | 25 | 30 | 10 | 200 | 300 |
| 6000 | 208 | 3 | 16.6 | 30 | 10 | 200 | 300 |
| 7500 | 240 | 1 | 31.3 | 40 | 8 | 290 | 375 |
| 7500 | 208 | 3 | 20.9 | 30 | 10 | 290 | 375 |
| 9000 | 240 | 1 | 37.5 | 50 | 8 | 360 | 450 |
| 9000 | 208 | 3 | 25 | 40 | 8 | 360 | 450 |
| 12000 | 240 | 1 | 50 | 70 | 6 | 450 | 700 |
| 12000 | 208 | 3 | 33.4 | 50 | 8 | 450 | 700 |
| 15000 | 240 | 1 | 62.5 | 80 | 4 | 600 | 900 |
| 15000 | 208 | 3 | 41.7 | 60 | 6 | 600 | 900 |
| 18000 | 208 | 3 | 50.3 | 70 | 6 | 750 | 1050 |
* Wire size/Breaker is recommendation only. Confirm with your licensed electrical contractor.
 |
.jpg) |
(for saunas up to 450 cubic feet)
|
|
CWM: |
100% Stainless Steal. |
CW-XR: |
100% Stainless Steal. |
CWS/CWM: |
Residential Warranty: 5 years. |
Commercial Warranty: |
1 year |
CW-XR: Residential Warranty: |
Lifetime. |
Commercial Warranty: |
3 year |
.jpg) |
 |
(for saunas over 450 cubic feet)
|
|
FM: |
100% Stainless Steal. |
FM-XR: |
100% Stainless Steal. |
CWS/CWM: |
Residential Warranty: 5 years. |
Commercial Warranty: |
1 year |
CW-XR: Residential Warranty: |
Lifetime. |
Commercial Warranty: |
3 year |
Residential models for home use (240 volt, 1 phase)
CWM & FM carry our standard five-year warranty.
CW-XR & FM-XR carry a Lifetime warranty on heating elements. Send back the broken part and we will send a replacement.
Be aware that some other's "lifetime" warranties may not be what they appear. If it's important to you, ask for details.
Some sauna heater manufacturers demand that you send the heater back to the factory for warranty repair. We find this to be preposterous. Expecting you to disconnect and ship a sauna cross country is an absurd expense. It is a disreputable tool intended to avoid providing quality service to customers.
Yet another heater offered with a lifetime warranty, considers the element to be a "consumable" product and such does not warranty the element.
Commercial models for public use (208 volt, 3 phase)
Commercial saunas receive intensely more abuse than do residential. So while we cannot offer the same warranty coverage, we still provide industry leading coverage for our CW-XR-C & FM-XR-C models.
CWS, CWM, FM carry our standard one-year warranty. (There is 30 days warranty on the elements).
CW-XR-C & FM-XR-C carry a Three-year warranty on heating elements.
(To our knowledge, no other sauna manufacturer offers a commercial warranty beyond one year).
Online prices are for residential models. Contact us for pricing on CW-XR-C and FM-XR-C commercial models.
CANADA:
Most Heaters are picked up at our factory. Shipping will be approximately $100 to $200 (including rocks) depending on the destination.
UNITED STATES
Freight will be confirmed before the order is finalized.
The U.S. heater freight table below is an estimate based your part of the country.
For zones 1 through 5, freight is included for wall hung heaters. There is freight surcharge for zones 6-10
and Large Heaters.
|
|||||||||||||||||||||||||||||||||||||||||
Contact us to discuss or send a drawing of what you have in mind. There are many great new designer features being incorporated in saunas; inspired by online designer showcase websites. We will help you balance function vs. fashion. We will advise on how best to utilize the space. And just importantly, we will tell you if we think your design is bad or unworkable.
